• TROP TEC SC 50.NI
  Description
  The TropTec SC 50.NI aluminium facade system provides a versatile mullion / transom constructions that combines flexibility and efficient fabrication with a stylish design offering an eye-catching framed look of the facade. An all-glass look is possible with the SG option (TropTec 50 SG.NI). The aluminium facade has been specifically developed to meet the requirements of markets with tropical climates, which makes it perfect in regions with high wind loads and torrential rain. Compatible with Schüco TropTec façade insert units Two different outward-opening, projected top-hung windows can fulfill almost every requirement of any façade project: The Schüco TropTec AW 48.NI insert unit provides a good basis for standard sizes with common fittings whereas the Schüco TropTec AW 58.NI is perfectly suitable for sophisticated façade projects with highest demands.


  ---




  ---

  Benefits
  Non-insulated aluminium mullion/transom façade system with horizontal and vertical cover caps
  Exclusive design due to minimal face widths of 50 mm and straightforward profi le geometries
  System solution for large dimensions and glass loads up to 300 kg
  Fully suitable façade attachment solution
  Reliablity and water tightness (720 Pa) due to overlapping drainage principle and three drainage levels
  Convincing structural performance levels due to high wind load resistance (2650 Pa)
  Good airborne sound insulation with standard insulating glass

• TROP TEC SC 50 SG.NI
  Description
  The Schüco TropTec SC 50 SG.NI structural glazing aluminium façade system can convince with its outstanding design offering an all-glass look on the outside with slender profiles of only 50 mm on the inside. The highly resilient mullion/transom construction combines energy efficency, flexibility and efficient fabrication. The special requirements of markets with tropical climates have been incorporated into the structural glazing façade system, which makes it perfect in regions with high wind loads and torrential rain. Compatible with Schüco TropTec façade insert units Two different outward-opening, projected top-hung windows can fulfil almost every requirement of any façade project: The Schüco TropTec AW 48.NI insert unit provides a good basis for standard sizes with common fittings whereas the Schüco TropTec AW 58.NI is perfectly suitable for sophisticated façade projects with highest demands.


  ---




  ---

  Benefits
  Non-insulated all-glass aluminium mullion/transom façade system
  Exclusive design due to minimal face widths of 50 mm and straightforward profile geometries
  Intelligent glass fi xing cleats without strctural bonding on-site
  System solution for large dimensions and glass loads up to 300 kg in ground floor
  Fully suitable façade attachment solution
  Reliablity and water tightness (720 Pa) due to overlapping drainage principle
  and three drainage levels Convincing structural performance levels due to high wind load resistance (2650 Pa)
  Good airborne sound insulation with standard insulating glass
